Server Board Rear I/O Layout
The following figure shows the layout of the rear I/O components for the server board.
A
Serial Port A
B
Video
14
®
Figure 9. Intel
Server Board S3420GP Rear I/O Layout
Intel order number E65697-010
C
NIC Port 1 (1 Gb) and Dual USB Port
Connector
D
NIC port 2 (1 Gb) and Dual USB Port
Connector
Intel® Server Board S3420GP TPS
Revision 2.4
