Functional Architecture
Turbo Boost converts any available power and thermal headroom into higher frequency

on active cores. At nominal marked processor frequency, many applications consume
less than the rated processor power draw.
Turbo Boost availability is independent of the number of active cores.

Maximum Turbo Boost frequency depends on the number of active cores and varies by

processor configuration.
The amount of time the system spends in Turbo Boost operation depends on workload,

operating environment, and platform design.
If the processor supports the Intel
an option to enable or disable this feature. The default state is enabled.
3.1.4

Simultaneous Multithreading (SMT)

® ®
Most Intel Xeon processors support Simultaneous Multithreading (SMT). The BIOS detects
processors that support this feature and enables the feature during POST.
If the processor supports this feature, the BIOS Setup provides an option to enable or disable
this feature. The default is enabled.
3.1.5 Enhanced Intel SpeedStep
Most processors support the Enhanced Intel SpeedStep
the processor operating ratio and voltage similar to the Thermal Monitor 1 (TM1) feature. The
BIOS implements this technology in conjunction with the TM1 feature. The BIOS enables a
combination of TM1 and TM2 according to the processor BIOS writer's guide.
3.2

Memory Subsystem

® ®
The Intel Xeon Processor 3400 Series has an Integrated Memory Controller (IMC) in its
®
package. Each Intel
memory. Each DDR3 channel in the IMC supports up to three DDR3 RDIMM slots or up to two
UDIMM slots. The DDR3 RDIMM frequency can be 800/1066/1333 MHz. DDR3 UDIMM
frequency can be 1066/1333 MHz. All RDIMMs and UDIMMs include ECC (Error Correction
Code) operation. Various speeds and memory technologies are supported.
® ®
Note: Intel Xeon Processor L3406 only supports DDR3 Unbuffered DIMM (UDIMM).
® TM
The Intel Core Processor i3-500 Series and Intel
Integrated Memory Controller (IMC) supports DDR3 protocols with two independent, 64-bit wide
channels each accessing one or two DIMMs. Only DDR3 UDIMM can be supported with the
® ®
Intel Core i3-500 Desktop Processor Series and Intel
RAS (Reliability, Availability, and Serviceability) is not supported on the Intel
S3420GP.
3.2.1

Memory Sizing and Configuration

®
The Intel Server Board S3420GP supports various memory module sizes and configurations.
These combinations of sizes and configurations are valid only for DDR3 DIMMs approved by
Intel Corporation.
18
®
Turbo Boost Technology feature, the BIOS Setup provides
®
Xeon Processor 3400 Series produces up to two DDR3 channels of
Intel order number E65697-010
Technology
®
®
technology. This technology changes
® ®
Pentium
®
Pentium
Intel® Server Board S3420GP TPS
Processor G6950 have an
®
Processor G6950.
®
Server Board
Revision 2.4
