Intel® Server Board S3420GP TPS
CPU Fan PWM
System Fan PWM
System temperature
+Vccp
+12V
+3.3V
+5.0V
+1.5V
+1.05V
+3.3V(standby)
5.2

SMBIOS

5.2.1

Data Storage

®
On Intel Server Board S3420GPLX and Intel
SMBIOS type 1, 2, 3 are from FRUSDR by BMC. But on Intel
SMBIOS type 1, 2, 3 are stored in BIOS flash during manufactory build, so it's also non-volatile
data storage.
BIOS retrieve the SMBIOS data from flash during POST, and it builds the SMBIOS type 1, 2, 3
into SMBIOS table and then transfers the control to operating system. Operating system and
system management software can use the SMBIOS table for system management purpose.
5.3

Event log and Viewer

5.3.1

Event Log Viewer in Setup

®
On Intel Server Board S3420GPLX and Intel
utility to view the event log. There is no IPMI support - the way to view the event log in BIOS
®
Setup, on Intel Server Board S3420GPV.
There is one page in BIOS setup for event log viewer. It is located in Error Manager Page.
Revision 2.4
Setup Item
Get and display CPU fan PWM periodically
Get and display system fan PWM periodically
Get and display current system temperature
monitored by system sensor
Get and display +Vccp voltage periodically
Get and display +12 voltage periodically
Get and display +3.3 voltage periodically
Get and display +5.0V voltage periodically
Get and display +1.5V voltage periodically
Get and display +1.05 voltage periodically
Get and display +3.3V(standby)voltage periodically
Intel order number E65697-010
Server Management Capability for Intel® Server Board S3420GPV
Comments
®
Server Board S3420GPLC with iBMC, the
®
Server Board S3420GPV,
®
Server Board S3420GPLC, there is a dedicated
45
