After converting spaces to polylines, you can convert the polylines back to spaces, as described in
Profiles, and Object Outlines to
NOTE If the net, usable, and gross boundaries are offset from the base boundary, a polyline is created for each boundary.
1 Select the zone containing spaces you want to convert to polylines, right-click, and click Create Polyline.
2 Specify the source of the polylines:
To create polylines only from directly attached spaces, enter D (Directly Attached Spaces) on the
command line.
To create polylines from all attached spaces, regardless of whether they are attached directly or through
subzones, press
Polylines are created on top of the specified spaces. You can edit them as any other polyline.
TIP When polylines lie above spaces, it can be difficult to select the space without the polyline. Try one of the following:
Press , and click the boundary. Then click until the space is highlighted.
CTRL
If the space hatch is displayed, click the hatch.
Enter qselect on the command line and filter for spaces.

Attaching Hyperlinks, Notes, or Files to a Zone

Use this procedure to attach hyperlinks, text notes, or files to a zone.
1 Double-click the zone you want to attach information to.
2 Click the Extended Data tab.
3 To add a hyperlink, click the setting for Hyperlink, and specify the link.
For more information about adding hyperlinks, see Add Hyperlinks to a Drawing" in AutoCAD Help.
4 Click the setting for Notes, and add a note. Then click OK.
5 Click the setting for Reference Documents.
6 Attach or detach reference files:
If you want to
attach a reference file
edit the description of a reference file
edit a reference file
detach a reference file
7 Click OK.

Zone Styles

The zone style can be used to control the display of the zone object, the zone and space connection lines, the zone
boundary, and the zone hatch. If you add a hatch to a zone, the hatch is also displayed in spaces attached to the zone
to indicate the relationship.
1710 | Chapter 36 Spaces
Spaces" on page 1618.
.
ENTER
Then
click , select a file, and click Open.
enter text for Description.
double-click the reference file name to start its application.
select the file name, and click
Converting Polylines,
.
