Intel® Server Chassis SC1400UP / Intel® Server Platform SR1425BK1-E
1.6
Control Panel
The Server Chassis SC1400UP control panel assembly is pre-assembled and modular in
design. The entire module assembly slides into a predefined slot in the front of the chassis.
Revision 1.0
Figure 4. Front Panel Feature Overview
A
Slim-line drive bay (CDROM or DVD/CDR or Floppy)
B
Control Panel
C
Hard Drive Fault/Activity LED
D
1" Hard Drive Bays
E
Chassis Handle
Figure 5. Control Panel Module
- 16 -
