1
Local Control Panel Kit Installation
Instructions
Use the instructions in this installation guide to install a Local Control Panel display on an
Intel® Server Chassis SC5300, Intel® Server Chassis SC5400, Intel® Entry Server Board
SC5275-E or Intel® Entry Server Chassis SC5299-E.
Note: For the Local Control Panel to function properly on an Intel® server board, you will need
to install an Intel® Management Module on the server board.
Note: The Local Control Panel is designed for use with a pedestal-configured chassis. It is not
intended for use on chassis in a rack-mount configuration.

Before You Begin

Before converting your system to a rack mount configuration, observe these safety
guidelines:
1. Turn off all peripheral devices connected to the server.
2. Turn off the server by pressing the power button on the front of the chassis. Then
unplug the AC power cord from the chassis or wall outlet.
3. Label and disconnect all peripheral cables and all telecommunications lines connected
to I/O connectors or ports on the back of the chassis.
4. Provide electrostatic discharge (ESD) protection by wearing an anti-static wrist strap
attached to a chassis ground - any unpainted metal surface - when handling
components.

Kit Content List

Each Local Control Panel Kit contains the following:
•
Local Control Panel (LCP)
•
LCP cable, pre-installed on LCP board
•
EMI shield
•
Grill work for Intel® Server Chassis SC5300/SC5400
•
Screws:
— Fastener "A"
— Fastener "CD"
— Fastener "FDU"
Local Control Panel Kit Install Guide 1
