Intel® Server Chassis SC1400UP / Intel® Server Platform SR1425BK1-E
1.3 Intel® Server Chassis SC1400UP System Components
A Power supply
B Chassis Intrusion Switch
C Full length PCI Add in card slot
D PCI Riser Card Assembly Placement
E System Fan Module
F CPU Air Duct Placement
Revision 1.0
G
H
I
J
K
L

Figure 2. Major Chassis Components

Control Panel
Hard Drive Bays
Chassis Handle
Slim Line Drive Bay
PS / Electronics Bay Isolation Air Baffle
Power Supply Fans
