Intel® Server Chassis SC1400UP / Intel® Server Platform SR1425BK1-E
3.1.1.2 CDROM or DVD-CDR Drive Use with or without Backplane present
Regardless of whether a backplane is present or not, the slim-line CDROM or DVD-CDR drive
is mated with an interposer card which provides the power and IO interconnects between the
drive, power supply and baseboard. The interposer card has three connectors; the first has 50
pins and is plugged directly into the drive connector. The connector has the following pinout.
RSV_LCM
RSV_GND
RST_IDE_S_L
IDE_SDD<7>
IDE_SDD<6>
IDE_SDD<5>
IDE_SDD<4>
IDE_SDD<3>
IDE_SDD<2>
IDE_SDD<1>
IDE_SDD<0>
GND
IDE_SDIOW_L
IDE_SIORDY
IRQ_IDE_S
IDE_SDA<1>
IDE_SDA<0>
IDE_SDCS0_L
IDE_SEC_HD_ACT_L
P5V
P5V
GND
GND
IDEP_ALE_H
The second connector has 4 pins and is cabled to the 2x3 pin power lead from the power
supply. The power cable for the drive is included in the SC1400UP in the form of a Y power
cable. Both ends of the Y cable are necessary when a slimline CD/DVD is used in conjunction
with a floppy installed in the hard drive bay. Both ends of this are identical and have the
following pinout.
Revision 1.0

Table 5. 50-pin CD-ROM connector Pinout (J6)

Name Pin
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49

Table 6. 4-pin CD-ROM power connector Pinout (J5)

Pin
1
2
3
4
Pin Name
2 RSV_RCM
4 GND
6 IDE_SDD<8>
8 IDE_SDD<9>
10 IDE_SDD<10>
12 IDE_SDD<11>
14 IDE_SDD<12>
16 IDE_SDD<13>
18 IDE_SDD<14>
20 IDE_SDD<15>
22 IDE_SDDREQ
24 IDE_SDIOR_L
26 GND
28 IDE_SDDACK_L
30 NC_IDEIO16_L
32 NC_CBL_DET_S
34 IDE_SDA<2>
36 IDE_SDCS1_L
38 P5V
40 P5V
42 P5V
44 GND
46 GND
48 GND
50
52 Unused (50 pin or 52 pin)
Name
P12V
GND
GND
P5V
