Intel® Server Chassis SC1400UP / Intel® Server Platform SR1425BK1-E
3.4
Hot-Swap SATA Backplane
The SC1400UP 1U SATA Hot-Swap Back Plane (HSBP) supports the following feature set:
®
QLogic
GEM424 enclosure management controller
o External non-volatile SEEPROMs
2
o Three I
C interfaces
o SATA and SATA-II extension compatible
o Compliance with SATA Accessed Fault Tolerant Enclosures (SAF-TE) specification,
version 1.00 and addendum
o Compliance with Intelligent Platform Management Interface 1.5 (IPMI)
Support for up to three SATA Drives
Hot Swap Drive support
Temperature Sensor
FRU EEPROM
One 2 x 3-pin Power Connector
IDE Connector provided for slim-line CDROM or DVD support
Floppy Connector provided for slim-line floppy support
Control Panel Connector
Drive Status LEDs
Revision 1.0
- 36 -
