Deployment Database Install; Pxe Server Install - Symantec ALTIRIS DEPLOYMENT SOLUTION 6.9 SP4 - V1.0 Manual

Client connection to server
Deployment web console information
Altiris Deployment Solution™ from Symantec User's Guide
Select Yes, I want to install PXE Server on a remote computer to install the
PXE Server on a remote computer. Enter the name of the computer and the path.
Enter the IP address for the PXE Server and the Deployment Server.
Enter the path where you want to install the PXE Server.
Select the pre-boot operating system that can be used as the default PXE boot
menu item. The pre-boot operating system options that are enabled depend on the
options you selected for the pre-boot operating systems in the Pre-boot Operating
Systems page. Example: If you select Linux in the Pre-boot Operating Systems
page, the Linux option is enabled as the default PXE boot menu item.
See Installing the automation agent
on page 366, and PXE Configuration Utility Help.
Select the protocol your managed computers can use to connect to the Deployment
Server.
Connect directly to Deployment Server. Installs the PXE Server using the Intel Pre-
boot eXecution Environment (for PXE-compliant computers only). You can use this
without PXE for faster access, as it goes directly to the IP address without searching.
If managed computers are on a different segment or if you are using the PXE Server
with an UNDI driver, click Connect directly to Deployment Server and enter the IP
address of the Deployment Server that the managed computers can connect to. Do not
change the port number unless the default is already being used.
Note
If you change the port number, you must change the client configurations.
Discover Deployment Server using TCP/IP multicast. Lets the managed
computers connect to any Deployment Server. To use multicasting and connect to a
specific Deployment Server, enter the name of the Deployment Server computer.
Multicasting cannot be used with the UNDI driver. If you want to use different drivers on
the PXE Server, you can create multiple PXE boot files after installing.
See Deployment agents
This feature lets you remotely manage Deployment installations, deploy and manage
Windows and Linux computers (both client and server editions) in real-time, and benefit
from many of the features available in the Deployment Console.
To install deployment web console
1. By default, the Deployment Web Console installs on the computer that is running
the installer. Select the On a remote computer option and browse to a computer
where you want to install. If you do not want to install the Deployment Web
Console, select the Do not install option.
2. If you want to change the default values, enter the Console port and Deployment
Web Console path for the installation.
on page 357,
on page 109.
Pre-boot operating system (simple)
368
