B.3.1 Card Service State Transitions

Table B-4
Current Service State
OOS-AU,AINS & SWDL
OOS-AU,AINS & UEQ
OOS-AU,FLT
OOS-AU,MEA
OOS-AU,SWDL
OOS-AU,UEQ
OOS-AUMA,FLT & MT
OOS-AUMA,MEA & MT
Cisco ONS 15454 Reference Manual, R8.5
B-4
ONS 15454 Card Service State Transitions (continued)
Action
Restart completed.
Remove the card.
Insert a valid card.
Insert an invalid card.
Delete the card.
Remove the card.
Delete the card.
Change the administrative state
to OOS,MT.
Reset the card.
Alarm/condition is cleared.
Remove the card.
Delete the card.
Change the administrative state
to OOS,MT.
Restart completed.
Remove the card.
Insert a valid card.
Insert an invalid card.
Delete the card.
Change the administrative state
to OOS,MT.
Remove the card.
Delete the card.
Change the administrative state
to IS.
Reset the card.
Alarm/condition is cleared.
Change the administrative state
to IS.
Remove the card.
Delete the card.
Appendix B Administrative and Service States
Next Service State
IS-NR
OOS-AU,AINS & UEQ
OOS-AU,AINS & SWDL
OOS-AU,AINS & MEA
OOS-AUMA,UAS & UEQ
OOS-AU,UEQ
OOS-AUMA,UAS
OOS-AUMA,FLT & MT
OOS-AU,SWDL
IS-NR
OOS-AU,UEQ
OOS-AUMA,UAS if the card is
valid
OOS-AUMA,MEA & UAS if the
card is invalid
OOS-AUMA,MEA & MT
IS-NR
OOS-AU,UEQ
OOS-AU,SWDL
OOS-AU,MEA
OOS-AUMA,UAS & UEQ
OOS-AUMA,MT & UEQ
OOS-AUMA,MT & UEQ
OOS-AUMA,UAS
OOS-AU,FLT
OOS-AUMA,MT & SWDL
OOS-MA,MT
OOS-AU,MEA
OOS-AUMA,MT & UEQ
OOS-AUMA,UAS if the card is
valid
OOS-AUMA,MEA & UAS if the
card is invalid
