Appendix A
Hardware Specifications
A.4.5 XC-VXC-10G Card Specifications
The XC-VXC-10G card has the following specifications:
•
•
A.4.6 AIC-I Card Specifications
The AIC-I card has the following specifications:
•
•
•
78-18106-01
Environmental
–
Operating temperature:
I-Temp (15454-XC-VXC-10G-T): –40 to 149 degrees Fahrenheit (–40 to +65 degrees Celsius)
Operating humidity: 5 to 85 percent, noncondensing
–
Power consumption: 67 W, 1.4 A, 228.62 BTU/hr
–
Dimensions
Height: 12.650 in. (321.3 mm)
–
–
Width: 0.716 in. (18.2 mm)
–
Depth: 9.000 in. (228.6 mm)
–
Card weight: 1.5 lb (0.6 kg)
Alarm inputs
–
Number of inputs: 12 without alarm extension panel (AEP), 32 with AEP
–
Opto coupler isolated
Label is customer provisionable.
–
Severity is customer provisionable.
–
Common 32 V output for all alarm inputs
–
Each input limited to 2 mA
–
Termination: Wire-wrap on backplane without AEP, on AEP connectors with AEP
–
Alarm outputs
–
Number of outputs: 4 (user configurable as inputs) without AEP, 16 with AEP
Switched by opto MOS (metal oxide semiconductor)
–
–
Triggered by definable alarm condition
–
Maximum allowed open circuit voltage: 60 VDC
–
Maximum allowed closed circuit current: 100 mA
–
Termination: Wire-wrap on backplane without AEP, on AEP connectors with AEP
Express orderwire/Local orderwire (EOW/LOW)
–
ITU-T G.711, ITU-T G.712, Telcordia GR-253-CORE
A-law, mu-law
–
Due to the nature of mixed coding, in a mixed-mode configuration (A-law/mu-law) the
Note
orderwire is not ITU-T G.712 compliant.
A.4.5 XC-VXC-10G Card Specifications
Cisco ONS 15454 Reference Manual, R8.5
A-15
