1.12.1 Wire-Wrap and Pin Connections
Figure 1-37
Table 1-24
Table 1-24
AEP Cable Wire
Black
White
Slate
Violet
Blue
Green
Yellow
Orange
Red
Brown
Figure 1-38
Cisco ONS 15454 Reference Manual, R8.5
1-58
AEP Wire-Wrap Connections to Backplane Pins
shows the backplane pin assignments and corresponding signals on the AIC-I and AEP.
Pin Assignments for the AEP
Backplane Pin AIC-I Signal
A1 GND
A2 AE_+5
A3 VBAT–
A4 VB+
A5 AE_CLK_P
A6 AE_CLK_N
A7 AE_DIN_P
A8 AE_DIN_N
A9 AE_DOUT_P
A10 AE_DOUT_N
is a circuit diagram of the alarm inputs (Inputs 1 and 32 are shown in the example).
Chapter 1 Shelf and Backplane Hardware
AEP Signal
AEP_GND
AEP_+5
VBAT–
VB+
AE_CLK_P
AE_CLK_N
AE_DOUT_P
AE_DOUT_N
AE_DIN_P
AE_DIN_N
