A.6.7 OC48 IR 1310 Card Specifications

Minimum transmit power, minimum receive power, and link loss budget might exceed standard
Note
specifications.
A.6.7 OC48 IR 1310 Card Specifications
The OC48 IR 1310 card has the following specifications:
•
•
•
•
•
Cisco ONS 15454 Reference Manual, R8.5
A-34
Line
– Bit rate: 2.49 Gbps
– Code: Scrambled NRZ
– Fiber: 1310-nm single-mode
– Loopback modes: Terminal and facility
Connectors: SC
–
Compliance: Telcordia GR-253-CORE
–
Transmitter
Maximum transmitter output power: 0 dBm
–
Minimum transmitter output power: –5 dBm
–
Center wavelength: 1280 to 1350 nm
–
– Nominal wavelength: 1310 nm
– Transmitter: Uncooled direct modulated DFB
Receiver
– Maximum receiver level: 0 dBm
– Minimum receiver level: –18 dBm
– Receiver: InGaAs InP photodetector
– Link loss budget: 13 dB minimum
Receiver input wavelength range: 1280 to 1350 nm
–
Environmental
Operating temperature:
–
C-Temp (15454-OC481IR1310): +23 to +131 degrees Fahrenheit (–5 to +55 degrees Celsius)
Operating humidity: 5 to 95 percent, noncondensing
–
Power consumption: 32.20 W, 0.67 A, 109.94 BTU/hr
–
Dimensions
Height: 12.650 in. (321.3 mm)
–
– Width: 0.716 in. (18.2 mm)
– Depth: 9.000 in. (228.6 mm)
– Weight not including clam shell: 1.8 lb (0.8 kg)
