Appendix A Hardware Specifications

A.6.19 OC192SR1/STM64IO Short Reach Card Specifications

The OC192SR1/STM64IO Short Reach card is designated as OC192-XFP in CTC.
Note
The OC192SR1/STM64IO Short Reach card has the following specifications:
•
•
•
•
•

A.6.20 OC192/STM64 Any Reach Card Specifications

Note The OC192/STM64 Any Reach card is designated as OC192-XFP in CTC.
The OC192/STM64 Any Reach card has the following specifications:
•
78-18106-01
Line
Bit rate: OC-192 (9.9520 Gbps)
–
Fiber: 1310-nm single-mode
–
Connectors: LC duplex connector for the XFP
–
Compliance: Telcordia GR-253-CORE
–
Transmitter
Maximum transmitter output power: –1 dBm
–
– Minimum transmitter output power: –6 dBm
Receiver
– Maximum receiver level: –1 dBm
– Minimum receiver level: –11 dBm
– Receiver input wavelength range: 1260 to 1565 nm
Environmental
– Operating temperature: 32 to +131 degrees Fahrenheit (0 to +55 degrees Celsius)
Operating humidity: 5 to 95 percent, noncondensing
–
Power consumption: 40.00 W, 0.83 A at –48 V, 136.49 BTU/hr
–
Dimensions
Height: 12.650 in. (321.3 mm)
–
Width: 0.716 in. (18.2 mm)
–
Depth: 9.000 in. (228.6 mm)
–
– Depth with backplane connector: 9.250 in. (235 mm)
– Weight not including clam shell: 3.1 lb (1.3 kg)
Line
– Bit rate: OC-192 (9.9520 Gbps)
– Fiber: 1310-nm single-mode for ONS-XC-10G-S1 XFP, 1550-nm single mode for
ONS-XC-10G-I2 and ONS-XC-10G-L2 XFPs
A.6.19 OC192SR1/STM64IO Short Reach Card Specifications
Cisco ONS 15454 Reference Manual, R8.5
A-47
