13.2.4 IP Scenario 4: Default Gateway on a CTC Computer

In Figure
announces that it can reach the ONS 152xx. The ONS 152xx is shown as an example; any network
element (NE) can be set up as an additional host.
Figure 13-4 IP Scenario 3: Using Proxy ARP with Static Routing
CTC Workstation
IP Address 192.168.1.100
Subnet Mark at CTC Workstation 255.255.255.0
Default Gateway = N/A
ONS 15454 #2
IP Address 192.168.1.20
Subnet Mask 255.255.255.0
Default Router = N/A
Static Routes = N/A
13.2.4 IP Scenario 4: Default Gateway on a CTC Computer
IP Scenario 4 is similar to IP Scenario 3, but Nodes 2 and 3 reside on different subnets, 192.168.2.0 and
192.168.3.0, respectively
ARP is not used because the network includes different subnets. For the CTC computer to communicate
with Nodes 2 and 3, Node 1 is entered as the default gateway on the CTC computer.
Cisco ONS 15454 Reference Manual, R8.5
13-6
13-4, Node 1 announces to Node 2 and 3 that it can reach the CTC host. Similarly, Node 3
ONS 15454 #1
IP Address 192.168.1.10
Subnet Mask 255.255.255.0
Default Router = N/A
Static Routes = Destination 192.168.1.100
SONET RING
(Figure 13-5). Node 1 and the CTC computer are on subnet 192.168.1.0. Proxy
Chapter 13
LAN A
Mask 255.255.255.255
Next Hop 192.168.1.10
ONS 152xx
IP Address 192.168.1.31
Subnet Mask 255.255.255.0
ONS 15454 #3
IP Address 192.168.1.30
Subnet Mask 255.255.255.0
Default Router = N/A
Static Routes = Destination 192.168.1.31
Mask 255.255.255.255
Next Hop 192.168.1.30
Management Network Connectivity
