Goodrive600 Series VFD Auto Station Programmable Card
Function
code
P27.24 PLC card AI1
P27.25 PLC card AO1
Length of data
sent from PLC
P27.26 card and PZD
communication
Name
PRO2.
0–10.00V/0.00–20.00mA
AI1 value on the PLC card.
0–10.00V/0.00–20.00mA
AO1 value on the PLC card.
0x00–0x28
Ones place: Quantity of data sent from
the PLC card and VFD (that is, quantity
of data sent from the PLC card + from
VFD sending table 1 + from VFD
sending table 2)
0: 0+24+0
1: 12+24+60
2: 24+24+60
3: 36+24+60
4: 48+24+60
5: 60+48+60
6: 72+24+60
7: 84+24+60
8: 96+96+96
object
Tens place: Card that communicates
with the PLC card through PZD (valid
only when the ones place of P27.26 is
5)
0: DP card
1: CANopen card
2: PN card
Note: P27.26 can be changed at any
time, but the change will only take effect
after the re-power on.
