Goodrive600 Series VFD Auto Station Programmable Card
Auto Station
interface variable
name
C_DEC1
C_P_Err
C_PID_GV_S
C_PID_FB_S
VFD
D element function
code
D7610
D7611
D7612
D7613
Interface description
0–36000 (corresponding to 0–3600.0s).
It is readable and writable.
When VFD DEC time 1 is set to a value
rather than 0 through the PLC card,
/ DEC time 1 specified by the value is
forcibly used (P00.12 is invalid). When
VFD DEC time 1 is set to 0 through the
PLC card, DEC time 1 (P00.12) set
through the VFD keypad is used.
PLC card user-defined fault. It is
readable and writable.
0: No fault (fault cleared)
1: PLC card user-defined fault 1
2: PLC card user-defined fault 2
3: PLC card user-defined fault 3
4: PLC card user-defined fault 4
5: PLC card user-defined fault 5
/
6: PLC card user-defined fault 6
7: PLC card user-defined fault 7
8: PLC card user-defined fault 8
9: PLC card user-defined fault 9
10: PLC card user-defined fault 10
The C_P_Err fault code ranges from 1
to 10. A fault code greater than 10 is
invalid.
-1000–1000 (corresponding to -100.0–
100.0%). It is readable and writable. To
enable the PLC card to set the VFD PID
/
reference value, set P00.00 to a value
rather than 2, P00.06=7 and
P09.00=11.
-1000–1000 (corresponding to -100.0–
100.0%). It is readable and writable.
/ To enable the PLC card to set the VFD
PID feedback value, set P00.00 to a
value rather than 2, P00.06=7 and
-43-
Appendix B
