Goodrive600 Series VFD Auto Station Programmable Card
Auto Station
interface variable
name
C_SetAO1
C_SetAO2
C_SetAO3
C_RunStopState
C_DiState
C_DoState
C_Ai1Val
VFD
D element function
code
D7627
D7628
D7629
D7630 P27.11
D7631 P27.22
D7632 P27.23
D7633 P27.24
Interface description
Bit3: RO1
Bit4: RO2
Bit5: RO3 (VFD I/O expansion card
output terminal RO3)
Bit6: RO4 (VFD I/O expansion card
output terminal RO4)
Bit7–Bit15: Reserved
0.00–10.00V/0.00–20.00mA. It is
readable and writable.
/
VFD analog output terminal AO1,
corresponding to -1000–1000/0–1000.
0.00–10.00V/0.00–20.00mA. It is
readable and writable.
/ VFD I/O expansion card analog output
terminal AO2, corresponding to -1000–
1000/0–1000.
/ Reserved.
It displays the current running status of
the PLC card. It is read only.
0: Stop
1: Run
0x00–0x3F. It is read only.
Input terminal status on the PLC card.
Bit5–Bit0 indicate PS6–PS1.
0x0–0x3. It is read only.
Output terminal status on the PLC card.
Bit0 indicates PRO1, and Bit1 indicates
PRO2.
0.00–10.00V/0.00–20.00mA. It is read
only.
To use the PLC card input terminal AI1,
you need to configure SM172, SM173,
and SM174. After the setting, the input
value (corresponding to 0–10000/0–
5000) of the PLC card input terminal AI1
can be read from SD172 or D7633
-45-
Appendix B
