Goodrive600 Series VFD Auto Station Programmable Card
2. Multi-step speed commands
Auto Station
interface
variable
name
C_MFrq
The multi-step speed setting cannot be greater than 16. The value 0 cannot be used, while
the default value is 1. This command is only used for channel selection. Each multi-step
speed must be set through P10 and require the setting of P00.06/P00.07.
3. ACC/DEC time setting commands
Auto Station
interface
variable
name
C_SpT
Table 4-3 Multi-step speed command interfaces
D element function
code
D7601
Table 4-4 ACC/DEC time setting command interfaces
D element function
code
D7602
VFD
0–16. It is readable and writable.
The options are as follows:
0: Disable
1: Multi-step speed 0
2: Multi-step speed 1
3: Multi-step speed 2
4: Multi-step speed 3
5: Multi-step speed 4
6: Multi-step speed 5
/ 7: Multi-step speed 6
8: Multi-step speed 7
9: Multi-step speed 8
10: Multi-step speed 9
11: Multi-step speed 10
12: Multi-step speed 11
13: Multi-step speed 12
14: Multi-step speed 13
15: Multi-step speed 14
16: Multi-step speed 15
VFD
0–4. It is readable and writable.
/
The options are as follows:
-18-
Auto Station programming interfaces
Interface description
Interface description
