Goodrive600 Series VFD Auto Station Programmable Card
Auto Station
interface variable
name
C_WrRece_PZD5
C_WrRece_PZD6
C_WrRece_PZD7
C_WrRece_PZD8
C_WrRece_PZD9
C_WrRece_PZD10
C_WrRece_PZD11
C_WrRece_PZD12
Note: The preceding parameters require the setting of function groups P15 and P16. For
details, see INVT Communication Expansion Card Operation Manual and Goodrive600
Series High-performance Multi-drive VFD Operation Manual. For example, if you want to set
the frequency for the VFD through the DP card, set P27.26=0x05 and P15.02=1, and set
PZD2 to the required value (and pay attention to the decimal place and unit conversion) on
the host computer. Then the set frequency is transferred to I_WrSend_PZD2 (D7425). If
I_WrSend_PZD2 (D7425) is directly sent to C_WrRece_PZD2 (D7637), the set frequency is
enabled on the VFD. If I_WrSend_PZD2 (D7425) is sent to C_WrRece_PZD2 (D7637) after
being processed, the processed set frequency is enabled on the VFD.
Auto Station
interface variable
name
I_RdSend_PZD1
I_RdSend_PZD2
I_RdSend_PZD3
I_RdSend_PZD4
I_RdSend_PZD5
I_RdSend_PZD6
I_RdSend_PZD7
I_RdSend_PZD8
I_RdSend_PZD9
I_RdSend_PZD10
VFD
D element function
code
D7640
D7641
D7642
D7643
D7644
D7645
D7646
D7647
Table 4-17 PZD reading channel interfaces
VFD
D element function
code
D7436
D7437
D7438
D7439
D7440
D7441
D7442
D7443
D7444
D7445
Auto Station programming interfaces
/ PZD5 sent to the VFD.
/ PZD6 sent to the VFD.
/ PZD7 sent to the VFD.
/ PZD8 sent to the VFD.
/ PZD9 sent to the VFD.
/ PZD10 sent to the VFD.
/ PZD11 sent to the VFD.
/ PZD12 sent to the VFD.
Status word (SW), which is the first PZD
/
sent from the VFD.
PZD2 sent from the VFD.
/
/ PZD3 sent from the VFD.
PZD4 sent from the VFD.
/
PZD5 sent from the VFD.
/
PZD6 sent from the VFD.
/
PZD7 sent from the VFD.
/
PZD8 sent from the VFD.
/
PZD9 sent from the VFD.
/
PZD10 sent from the VFD.
/
-32-
Interface description
Interface description
