Goodrive600 Series VFD Auto Station Programmable Card
Auto Station
interface variable
name
C_MoP1
C_MoP2
C_MoP3
C_MoP4
C_MoP5
C_MoP6
C_MoP7
C_MoP8
C_MoP9
C_MoP10
C_VF_SET
C_UP_FRQ
C_SetDo
VFD
D element function
code
D7614 P27.12
D7615 P27.13
D7616 P27.14
D7617 P27.15
D7618 P27.16
D7619 P27.17
D7620 P27.18
D7621 P27.19
D7622 P27.20
D7623 P27.21
D7624
D7625
D7626
Interface description
P09.02=9.
MoP1 value monitored by the VFD. It is
readable and writable.
MoP2 value monitored by the VFD. It is
readable and writable.
MoP3 value monitored by the VFD. It is
readable and writable.
MoP4 value monitored by the VFD. It is
readable and writable.
MoP5 value monitored by the VFD. It is
readable and writable.
MoP6 value monitored by the VFD. It is
readable and writable.
MoP7 value monitored by the VFD. It is
readable and writable.
MoP8 value monitored by the VFD. It is
readable and writable.
MoP9 value monitored by the VFD. It is
readable and writable.
MoP10 value monitored by the VFD. It
is readable and writable.
0–1000 (corresponding to 0–100.0%). It
is readable and writable.
/ To enable the PLC card to set the VFD
VF voltage, set P04.00=5 (user-defined
V/F) and P04.27=12.
/ Frequency upper limit. Reserved.
C_SetDo is an unsigned 16-bit number,
which is readable and writable.
Each bit represents a unique digital
output terminal of the VFD:
/
Bit0: Y1
Bit1: HDO (for digital output)
Bit2: Y2 (VFD I/O expansion card
output terminal Y2)
