INVT Goodrive600 VFD Series Operation Manual page 38

Goodrive600 Series VFD Auto Station Programmable Card
Appendix A D elements for exchange between the PLC card
Auto Station
interface variable
name
I_SetFrq
I_OutputFrq
I_LineSetFrq
I_DiState
I_DoState
I_TorqSet
I_CounterVal
I_AI1
VFD
D element function
code
D7400 P17.00
D7401 P17.01
D7402 P17.02
D7403 P17.12
D7404 P17.13
D7405 P17.15
D7406 P17.18
D7407 P17.19
and VFD
Interface description
Set frequency of the VFD. It is read
only.
Output frequency of the VFD. It is read
only.
Ramp reference frequency of the VFD.
It is read only.
I_DiState is an unsigned 16-bit number,
which is read only.
Each bit represents a unique digital
input terminal on the VFD:
Bit0: S1
Bit1: S2
Bit2: S3
Bit3: S4
Bit4: S5 (VFD I/O expansion card input
terminal S5)
Bit5: S6 (VFD I/O expansion card input
terminal S6)
Bit6: S7 (VFD I/O expansion card input
terminal S7)
Bit7: S8 (VFD I/O expansion card input
terminal S8)
Bit8: HDIA (for digital input)
Bit9: HDIB (for digital input)
Bit10–Bit15: Reserved
Digital output terminal status of the
VFD. It is read only.
Torque reference value of the VFD. It is
read only.
Count value of the VFD. It is read only.
0.00–10.00V/0.00–20.00mA. It is read
only.
VFD analog input terminal AI1,
