Goodrive600 Series VFD Auto Station Programmable Card
Auto Station
interface variable
name
I_WrSend_PZD7
I_WrSend_PZD8
I_WrSend_PZD9
I_WrSend_PZD10
I_WrSend_PZD11
I_WrSend_PZD12
I_RdSend_PZD1
I_RdSend_PZD2
I_RdSend_PZD3
I_RdSend_PZD4
I_RdSend_PZD5
I_RdSend_PZD6
I_RdSend_PZD7
I_RdSend_PZD8
I_RdSend_PZD9
I_RdSend_PZD10
I_RdSend_PZD11
I_RdSend_PZD12
I1_Reserve8–55
I_OutputVolt
I_OutputCurrent
I_MotorRpm
I_TorqCurrent
I_MagCurrent
I_MotorPower
I_OutputTorq
I_EstMotorFrq
D element function
D7430
D7431
D7432
D7433
D7434
D7435
D7436
D7437
D7438
D7439
D7440
D7441
D7442
D7443
D7444
D7445
D7446
D7447
D7448–D7495
D7500
D7501
D7502
D7503
D7504
D7505
D7506
D7507
VFD
code
PZD7 sent from the DP/CANopen/PN
/
card.
PZD8 sent from the DP/CANopen/PN
/
card.
PZD9 sent from the DP/CANopen/PN
/
card.
PZD10 sent from the DP/CANopen/PN
/
card.
PZD11 sent from the DP/CANopen/PN
/
card.
PZD12 sent from the DP/CANopen/PN
/
card.
Status word (SW), which is the first PZD
/
sent from the VFD.
/ PZD2 sent from the VFD.
/ PZD3 sent from the VFD.
/ PZD4 sent from the VFD.
/ PZD5 sent from the VFD.
/ PZD6 sent from the VFD.
/ PZD7 sent from the VFD.
/ PZD8 sent from the VFD.
/ PZD9 sent from the VFD.
/ PZD10 sent from the VFD.
/ PZD11 sent from the VFD.
/ PZD12 sent from the VFD.
/ Reserved
P17.03 Output voltage. It is read only.
P17.04 Output current. It is read only.
P17.05 Motor rotation speed. It is read only.
P17.06 Torque current. It is read only.
P17.07 Exciting current. It is read only.
P17.08 Motor power. It is read only.
P17.36 Output torque. It is read only.
Estimated motor frequency. It is read
P17.10
only.
-37-
Interface description
Appendix B
