Goodrive600 Series VFD Auto Station Programmable Card
Auto Station
interface
variable name
4.10 DP/CANopen/PN communication channel
The VFD uses function code P27.26 to control the data volume (send by two groups)
exchanged between the PLC card and VFD to reduce communication time. By default,
P27.26 is 0x03, indicating only the data exchanged through the interfaces mentioned earlier
is involved. If you want to enable the DP/CANopen/PN communication channel for the PLC
card, change the value of P27.26 accordingly. P27.26 is described in the following.
Function
Name
code
Length of data
sent from PLC
P27.26 card and PZD
communication
object
VFD
D element function
code
Table 4-15 Description of function code P27.26
0x00–0x28
Ones place: Quantity of data sent from
the PLC card and VFD (that is, quantity of
data sent from the PLC card + from VFD
sending table 1 + from VFD sending table
2)
0: 0+24+60
1: 12+24+60
2: 24+24+60
3: 36+24+60
4: 48+24+60
5: 60+48+60
6: 72+24+60
7: 84+24+60
8: 96+96+96
Tens place: Card that communicates with
the PLC card through PZD (valid only
when the ones place of P27.26 is 5)
0: DP card
1: CANopen card
2: PN card
Note: P27.26 can be changed at any
Auto Station programming interfaces
Interface description
card. It is read only.
0: Stop
1: Run
Description
-29-
Default Modify
0x03
○
