Goodrive600 Series VFD Auto Station Programmable Card
The value cannot be greater than 3. The default value is 0. This command is only used for
channel selection. ACC/DEC time has to be set through the respective function codes.
4.4 Interfaces for setting function parameters
The VFD provides the PLC card with certain function parameter interfaces. You can set these
parameters on the Auto Station.
Auto Station
interface
variable name
C_FRQ_SET
C_TOR_SET
C_F_UP_FWD
C_F_UP_REV
C_T_UP_ELEC
Table 4-5 Interfaces for setting VFD function parameters
VFD
D element function
code
D7603
D7604
D7605
D7606
D7607
0: ACC/DEC time 1
1: ACC/DEC time 2
2: ACC/DEC time 3
3: ACC/DEC time 4
0–63000 (corresponding to 0–630.00Hz). It is
readable and writable.
/
To enable the PLC card to set the VFD
frequency, set P00.06/P00.07=14.
-3000–3000 (corresponding to -300.0%–
300.0%). It is readable and writable.
/
To enable the PLC card to set the VFD torque,
set P03.11=12 and P03.32=1.
0–63000 (corresponding to 0–630.00Hz). It is
readable and writable.
/ To enable the PLC card to set forward torque
upper limit, set P03.32=1, P00.00 to a value
rather than 2, and P03.14=11.
0–63000 (corresponding to 0–630.00Hz). It is
readable and writable.
/ To enable the PLC card to set reverse
frequency upper limit, set P03.32=1, P00.00 to
a value rather than 2, and P03.15=11.
0–3000 (corresponding to 0–300.0%). It is
readable and writable.
/ To enable the PLC card to set electromotion
torque upper limit, set P03.32=1, P00.00 to a
value rather than 2, and P03.18=10.
-19-
Auto Station programming interfaces
Interface description
