INVT Goodrive600 VFD Series Operation Manual page 41

Goodrive600 Series VFD Auto Station Programmable Card
Auto Station
interface variable
name
I_DC_Volt
I_LineSpeed
I_PowerFactor
I_CurRuntime
I_CurStage
I_SynMagAngle
I_MagCurSet
I_TorqCurSet
I_LineAC_Cur
I_MotorOutTorq
I_T_Sink
I_T_Invert
I_InvertRuntime
I_ElectricHigh
I_ElectricLow
I_FaultType
I_FaultRunFrq
I_FaultLineFrq
I_FaultOutVolt
I_FaultOutCur
I_FaultDcVolt
I_FaultTemper
VFD
D element function
code
D7508 P17.11
D7509 P17.16
D7510 P17.25
D7511 P17.26
D7512 P17.27
D7513 P17.29
D7514 P17.33
D7515 P17.34
D7516 P17.35
D7517 P17.09
D7518 P07.11
D7519 P07.12
D7520 P07.14
D7521 P07.15
D7522 P07.16
D7523 P07.27
D7524 P07.33
D7525 P07.34
D7526 P07.35
D7527 P07.36
D7528 P07.37
D7529 P07.38
Interface description
DC bus voltage. It is read only.
Linear speed. It is read only.
Motor power factor. It is read only.
Duration of this run. It is read only.
Simple PLC and actual step of
multi-step speed. It is read only.
Pole angle of open-loop SM. It is read
only.
Exciting current reference. It is read
only.
Torque current reference. It is read only.
AC incoming current. It is read only.
Motor output torque. It is read only.
Rectifier bridge module temperature. It
is read only.
Inverter module temperature. It is read
only.
Accumulative running time. It is read
only.
VFD electricity consumption high bits. It
is read only.
VFD electricity consumption low bits. It
is read only.
Type of present fault. It is read only.
Running frequency at present fault. It is
read only.
Ramp reference frequency at present
fault. It is read only.
Output current at present fault. It is read
only.
Output current at present fault. It is read
only.
Bus voltage at present fault. It is read
only.
Max. temperature at present fault. It is
-38-
Appendix B
