INVT Goodrive600 VFD Series Operation Manual page 52

Goodrive600 Series VFD Auto Station Programmable Card
Function
code
P27.12 C_MoP1
P27.13 C_MoP2
P27.14 C_MoP3
P27.15 C_MoP4
P27.16 C_MoP5
P27.17 C_MoP6
P27.18 C_MoP7
P27.19 C_MoP8
P27.20 C_MoP9
P27.21 C_MoP10
PLC card
P27.22 digital input
terminal status
PLC card
P27.23 digital output
terminal status
Name
card.
0: Stop
1: Run
0–65535
PLC card MoP1 value monitored by the
VFD.
0–65535
PLC card MoP2 value monitored by the
VFD.
0–65535
T PLC card MoP3 value monitored by
the VFD.
0–65535
PLC card MoP4 value of the PLC.
0–65535
PLC card MoP5 value monitored by the
VFD.
0–65535
PLC card MoP6 value monitored by the
VFD.
0–65535
PLC card MoP7 value monitored by the
VFD.
0–65535
PLC card MoP8 value monitored by the
VFD.
0–65535
PLC card MoP9 value monitored by the
VFD.
0–65535
PLC card MoP10 value monitored by
the VFD.
0x00–0x3F
Input terminal status on the PLC card.
Bit5–Bit0 indicate PS6–PS1.
0x0–0x3
Output terminal status on the PLC card.
Bit0 indicates PRO1, and Bit1 indicates
Description
-49-
Appendix B
Default Modify
0
●
0
●
0
●
0
●
0
●
0
●
0
●
0
●
0
●
0
●
0x00
●
0x00
●
