Goodrive600 Series VFD Auto Station Programmable Card
cleared. If the switch is turned from STOP to RUN, output is executed with a delay of 0.5s.
SW1
RUN
STOP
Output of the PLC card indicates the control command that the PLC card sends to the VFD.
Hardware output
PRO1/PRO2/AO1/External fault.
If the RUN/STOP switch is turned to STOP: if the Auto Station is being used for

monitoring now, the RUN button on the Auto Station is invalid and turned to the STOP
state; if the RUN/STOP button on the Auto Station is turned to STOP during the online
monitoring debugging, PLC programs are suspended, PLC output is cleared, and the
VFD coasts to stop.
If the RUN/STOP switch is turned to RUN: if the Auto Station is being used for

monitoring now, the RUN/STOP button on the Auto Station is valid and turned to the
RUN state; PLC programs resume running, but the hardware PLC output activates
with a delay of 0.5s, and the running command that is given to the VFD again (the
VFD not in running protection state) also activates with a delay of 0.5s.
The correct operation procedure is as follows: Before downloading programs from the Auto
Station to the PLC card, turn the RUN/STOP switch on the PLC card to STOP. After the
download, turn the RUN/STOP switch on the PLC card to RUN. In addition, you can debug
code online and perform monitoring and use the RUN/STOP button on the Auto Station to
perform control the output of the PLC card.
You can enable the monitoring mode of the Auto Station or check the value of VFD function
code P27.11 to view the running status of the PLC card.
Table 4-14 Interface for viewing the running status of the PLC card
Auto Station
interface
variable name
C_RunStopState
Table 4-13 Description of SW1 on the PLC card
Description
To run PLC
programs
To stop PLC
programs
includes VFD
VFD
D element function
code
D7630 P27.11
Auto Station programming interfaces
PLC programs are executed. If the switch is
turned from STOP to RUN, output is executed
with a delay of 0.5s.
Stopping PLC programs will clear PLC output.
AO1/AO2/RO1/RO2/Y1/Y2
Interface description
It displays the current running status of the PLC
-28-
Description
and PLC card
