Goodrive600 Series VFD Auto Station Programmable Card
Auto Station
interface variable
name
C_Ao1Val
C_Reserve5
C_WrRece_PZD1
C_WrRece_PZD2
C_WrRece_PZD3
C_WrRece_PZD4
C_WrRece_PZD5
VFD
D element function
code
D7634 P27.25
D7635
D7636
D7637
D7638
D7639
D7640
Interface description
(C_Ai1Val). For SM172, the value 1
indicates enabling input, while the
default value 0 indicates disabling
input.
For SM174, the value 1 indicates
current input, while the default value 0
indicates voltage input.
SD173 specifies the sampling count.
The value is also synchronized to
P27.24.
0.00–10.00V/0.00–20.00mA. It is
readable and writable.
To use the PLC card output terminal
AO1, you need to configure SM178 and
SM179. After the setting, a value
(corresponding to 0–10000/0–10000)
can be written to SD178 to enable AO1
to output current or voltage.
For SM178, the value 1 indicates
enabling output, while the default value
0 indicates disabling output.
For SM179, the value 1 indicates
current output, while the default value 0
indicates voltage output. The value is
also synchronized to P27.25.
Note: D7634(C_Ao1Val) only has the
display function and cannot be used for
programming. That is, writing a value to
D7634(C_Ao1Val) does not change the
output value of AO1.
/ Reserved
/ CW sent to the VFD.
/ PZD2 sent to the VFD.
/ PZD3 sent to the VFD.
/ PZD4 sent to the VFD.
/ PZD5 sent to the VFD.
