Goodrive600 Series VFD Auto Station Programmable Card
Auto Station
interface
variable name
I_PID_Set
I_PID_Feedback
I_PID_Output
I_EncoderFrq
I_CardEnable
Table 4-7 Interfaces for viewing function parameters (group 2)
Auto Station
interface
variable name
I_OutputVolt
I_OutputCurrent
I_MotorRpm
I_TorqCurrent
I_MagCurrent
I_MotorPower
I_OutputTorq
I_EstMotorFrq
I_DC_Volt
I_LineSpeed
I_PowerFactor
I_CurRuntime
I_CurStage
I_SynMagAngle
I_MagCurSet
I_TorqCurSet
I_LineAC_Cur
I_MotorOutTorq
I_CtrlMode
VFD
D element function
code
D7412 P17.23
D7413 P17.24
D7414 P17.38
D7415 P18.00
D7416 P27.00
VFD
D element function
code
D7500 P17.03
D7501 P17.04
D7502 P17.05
D7503 P17.06
D7504 P17.07
D7505 P17.08
D7506 P17.36
D7507 P17.10
D7508 P17.11
D7509 P17.16
D7510 P17.25
D7511 P17.26
D7512 P17.27
D7513 P17.29
D7514 P17.33
D7515 P17.34
D7516 P17.35
D7517 P17.09
D7545 P17.40
Auto Station programming interfaces
Interface description
PID reference value. It is read only.
PID feedback value. It is read only.
Process PID output. It is read only.
Actual frequency of the encoder. It is read only.
Indicates whether to enable the PLC card,
which is reserved. It is read only.
Interface description
Output voltage. It is read only.
Output current. It is read only.
Motor rotation speed. It is read only.
Torque current. It is read only.
Exciting current. It is read only.
Motor power. It is read only.
Output torque. It is read only.
Estimated motor frequency. It is read only.
DC bus voltage. It is read only.
Linear speed. It is read only.
Motor power factor. It is read only.
Duration of this run. It is read only.
Simple PLC and actual step of multi-step speed.
It is read only.
Pole angle of open-loop SM. It is read only.
Exciting current reference. It is read only.
Torque current reference. It is read only.
AC incoming current. It is read only.
Motor output torque. It is read only.
Motor control mode. It is read only.
