Goodrive600 Series VFD Auto Station Programmable Card
Auto Station
interface variable
name
I_WrP3
I_WrP4
I_WrP5
I_WrP6
I_WrP7
I_WrP8
I_WrP9
I_WrP10
I_CtrlMode
I_TorqUpElec
I_TorqUpGen
I_TorqFrqUpFwd
I_TroqFrqUpRev
I2_Reserve1–10
I2_Reserve11–46 D7560–D7595
C_CTRL
D element function
D7537
D7538
D7539
D7540
D7541
D7542
D7543
D7544
D7545
D7546
D7547
D7548
D7549
D7550–D7559
D7600
VFD
code
Value that the VFD writes to WrP3 on
P27.03
the PLC card. It is read only.
Value that the VFD writes to WrP4 on
P27.04
the PLC card. It is read only.
Value that the VFD writes to WrP5 on
P27.05
the PLC card. It is read only.
Value that the VFD writes to WrP6 on
P27.06
the PLC card. It is read only.
Value that the VFD writes to WrP7 on
P27.07
the PLC card. It is read only.
Value that the VFD writes to WrP8 on
P27.08
the PLC card. It is read only.
Value that the VFD writes to WrP9 on
P27.09
the PLC card. It is read only.
Value that the VFD writes to WrP10 on
P27.10
the PLC card. It is read only.
P17.40 Motor control mode. It is read only.
Electromotive torque upper limit. It is
P17.41
read only.
Braking torque upper limit. It is read
P17.42
only.
Frequency upper limit of forward
P17.43
running in torque control. It is read only.
Frequency upper limit of reverse
P17.44
running in torque control. It is read only.
/ Reserved
/ Reserved
0–10. It is readable and writable. The
options are as follows:
0: Disable
1: Run forward (FWD)
/
2: Run reversely (REV)
3: Jog forward
4: Jog reversely
5: Decelerate to stop
-40-
Interface description
Appendix B
