Goodrive600 Series VFD Auto Station Programmable Card
Table 4-1 Interfaces corresponding to the digital inputs and outputs of the VFD and PLC card
Auto Station
interface
D/X/Y element
variable
name
I_DiState
C_SetDo
VFD
function
code
D7403 P17.12
D7626 /
Auto Station programming interfaces
Interface description
I_DiState is an unsigned 16-bit number, which is
read only.
Each bit represents a unique digital input
terminal on the VFD:
Bit0: S1
Bit1: S2
Bit2: S3
Bit3: S4
Bit4: S5 (VFD I/O expansion card input terminal
S5)
Bit5: S6 (VFD I/O expansion card input terminal
S6)
Bit6: S7 (VFD I/O expansion card input terminal
S7)
Bit7: S8 (VFD I/O expansion card input terminal
S8)
Bit8: HDIA (for digital input)
Bit9: HDIB (for digital input)
Bit10–Bit15: Reserved
C_SetDo is an unsigned 16-bit number, which is
readable and writable.
Each bit represents a unique digital output
terminal of the VFD:
Bit0: Y1
Bit1: HDO (for digital output)
Bit2: Y2 (VFD I/O expansion card output
terminal Y2)
Bit3: RO1
Bit4: RO2
Bit5: RO3 (VFD I/O expansion card output
terminal RO3)
Bit6: RO4 (VFD I/O expansion card output
terminal RO4)
Bit7–Bit15: Reserved
