Goodrive600 Series VFD Auto Station Programmable Card
4.8 Interfaces for monitoring PLC card data
The VFD provides a group of function codes for the PLC card to monitor PLC card data.
You can perform secondary development on the Auto Station to send to-be-monitored PLC
card data to Auto Station programming interfaces corresponding to P27. The VFD can
monitor the data through P27. A total of 10 Auto Station interfaces can be defined.
Auto Station
interface
variable name
C_MoP1
C_MoP2
C_MoP3
C_MoP4
C_MoP5
C_MoP6
C_MoP7
C_MoP8
C_MoP9
C_MoP10
4.9 RUN/STOP switch and PLC card running status
The RUN/STOP switch on the PLC card is used to start or stop the PLC program and does
not affect PLC program download. If the switch is turned to STOP, the PLC program is
stopped. If the switch is turned to RUN, the PLC program runs. The status can be viewed
through P27.11. If the switch is turned from RUN to STOP, the control command given to the
VFD is cleared (if the VFD is running, the VFD stops at this situation), hardware output
(including VFD AO1/AO2/RO1/RO2/Y1/Y2 and PLC card PRO1/PRO2/AO1/External fault) is
Table 4-12 Interfaces for monitoring PLC card data
VFD
D element function
code
D7614 P27.12
D7615 P27.13
D7616 P27.14
D7617 P27.15
D7618 P27.16
D7619 P27.17
D7620 P27.18
D7621 P27.19
D7622 P27.20
D7623 P27.21
Auto Station programming interfaces
Interface description
MoP1 value monitored by the VFD. It is readable
and writable.
MoP2 value monitored by the VFD. It is readable
and writable.
MoP3 value monitored by the VFD. It is readable
and writable.
MoP4 value monitored by the VFD. It is readable
and writable.
MoP5 value monitored by the VFD. It is readable
and writable.
MoP6 value monitored by the VFD. It is readable
and writable.
MoP7 value monitored by the VFD. It is readable
and writable.
MoP8 value monitored by the VFD. It is readable
and writable.
MoP9 value monitored by the VFD. It is readable
and writable.
MoP10 value monitored by the VFD. It is
readable and writable.
