Fig. 39: Infusion stand height adjustment
5.15.8 Mounting / removing the cable donut for EPoS rail
3
1
2
Fig. 40: Mounting / removing the cable donut
Moduevo
IFU 009001001 EN 13
2
1
4
Operation and use
Infusion stand height adjustment
1. Hold the rod of the infusion stand with
1
one hand.
2. Open the flap .
2
Ø The height of the infusion stand can be
adjusted.
3. Adjust the height of the infusion stand rod
to the desired position.
4. Close the flap.
Ø The infusion stand is secured in the de-
sired position.
Mounting the cable donut for EPoS rail
1. Press and hold the pin
donut.
Ø The clamp is opened.
2. Place the clamp
2
and in doing so hook one side of the
clamp behind the EPoS rail.
4
3. Swivel the clamp
2
rail .
3
Ø The other side of the clamp is hooked
in behind the EPoS rail.
4. Release the pin
1
Ø The clamp is closed.
5. Ensure that the cable donut is firmly posi-
tioned.
Remove the cable donut
1. Press and hold the pin
Ø The clamp is opened.
2. Swivel the cable donut to the side and re-
move from the EPoS rail.
5
Accessories
on the cable
1
on the EPoS rail
3
fully onto the EPoS
on the cable donut.
on the donut.
1
