Operation and use
5
Control panel for light presets
5.5 Control panel for light presets
Fig. 12: Control panel for light presets
5.6 Adjusting the lighting
Fig. 13: Adjusting the lighting
54 / 104
1
2
3
1
Beam light, distributor light and floor light can
be adjusted with the control panel on the wall
or distributor module:
• Key [ON / OFF] for beam light
• Key [ON / OFF] for distributor light
• Key [ON / OFF] for floor light
Switching on the lighting
1. Press the appropriate button [ON / OFF]
on the control panel for the beam light,
1
distributor light or floor light.
Ø The respective light is switched on with
the preset brightness.
Ø The button lights up and the individual
2
bars alongside the button are lit in ac-
cordance with the set brightness.
Adjusting brightness
1. Drag a finger over the bar
appropriate button, or press the bar:
• To the right, to increase brightness.
• To the left, to decrease brightness.
Switching off the lighting
1. Press the appropriate button [ON / OFF]
on the control panel for the beam light,
1
distributor light or floor light.
Ø The respective light will be switched off.
Ø The brightness setting is saved and
used again the next time the light is
switched on.
1
2
3
next to the
2
Moduevo
IFU 009001001 EN 13
