5 Operation and use
5.1 Button assignment and touch sensors of the hand control
Fig. 6: Button assignment and touch sensors of
the hand control
5.2 Mounting / removing the hand control
1
4
Fig. 7: Mount the hand control
Moduevo
IFU 009001001 EN 13
Button assignment and touch sensors of the hand control
1
2
3
4
3
8
2
5
The hand control has touch sensors and a
control panel. The control panel consists of
three buttons. The buttons may control EN-
ERGY or CARGOLIFT depending on the con-
figuration
• [Up] button
ENERGY / CARGOLIFT are raised.
• Lock button
Brake in Axis 1 is locked, brake in Axis 2
remains unlocked.
• [Down] button
ENERGY / CARGOLIFT are lowered.
• Handle with touch sensors
The brakes are released with the touch
sensors on the handle.
Prerequisites:
• Allen wrench is required.
Mount the hand control
1. Slide the slider
2. Undo the screw
Allen wrench.
6
Ø The clamp
3. Place the hand control
7
and in doing so hook one side of the
5
clamp
4. Swivel the hand control fully onto the
EPoS rail.
Ø The other side of the clamp is hooked
in behind the EPoS rail.
5. Firmly tighten the screw
with the Allen wrench.
Ø The clamp
6. Ensure that the hand control is firmly posi-
tioned.
Operation and use
1
2
3
4
back.
1
on the clamp with the
2
is opened.
3
on the EPoS rail
4
behind the EPoS rail.
6
on the clamp
7
is closed.
8
5
