Illustration
Tab. 8: Distributors modules
Moduevo
IFU 009001001 EN 13
Modules of the medical ceiling supply units
Description
PLG-II SKY distributor module
▪ The PLG-II SKY distributor module can be height ad-
justed via the hinge and is mounted directly to the
spacer tube. PLG-II SKY only provides mounting
points for connections.
SKY Classic distributor module
▪ Horizontal distributor module
▪ 5 panels
▪ 2 mechanical EPoS rails
SKY Classic module is available in the following lenghts:
▪ 470 mm
▪ 670 mm
▪ 870 mm
SKY ADV (Advance) distributor module
▪ Horizontal distributor module
▪ 5 panels
▪ 2 EPoS rails
SKY ADV module is available in the following lenghts:
▪ 470 mm
▪ 670 mm
▪ 870 mm
The Rack system is optional and available in the follow-
ing lengths:
▪ 400 mm (as shown in the figure)
▪ 800 mm
Product configuration
