Product configuration
3
Modules of the medical ceiling supply units
3.1.2.1 Product model: ENERGY
ENERGY refers to the motorised arm which can be both rotated and adjusted vertically using the
motor. The motor is installed either between the spacer tube and the beam or between the upper
and lower beams. Only a beam with a length of 1000 mm is attached to the motor.
Illustration
Tab. 7: Product model: ENERGY
28 / 104
Description
ENERGY with single arm. The motor is installed
between the spacer tube and the beam.
Length of the motorized beam.
▪ 1000 mm
ENERGY with double arm.
For an ENERGY with double arm, the motor is installed
between the beams. The beam with the length of 1000
mm is mounted at the motor below. The beams may not
be configured the other way round.
The upper mechanical HEAVY beams are available in
the following lengths:
▪ 600 mm
▪ 900 mm
▪ 1200 mm
▪ 1500 mm
The upper mechanical LIGHT beams are available in the
following lengths:
▪ 600 mm
▪ 900 mm
▪ 1200 mm
