Mounting / removing the hand control
Fig. 8: Mount the hand control
Fig. 9: Remove the hand control
52 / 104
9
4
3
2
1
7. Firmly tighten the setting screw
Allen wrench.
8. Check the secure connection between the
hand control and the EPoS rail.
Prerequisites:
• The hand control is separated from the
voltage supply.
• Opening of screw on clamp is free.
• Allen wrench is present.
Remove the hand control
1. Undo the setting screw
wrench.
2. Hold the hand control
3. Undo the screw
2
Allen wrench.
Ø The clamp
is opened.
4
4. Swivel the hand control
remove from the EPoS rail.
with the
9
with the Allen
1
.
3
on the clamp with the
to the side and
3
