Operation and use
5
Accessories
5.15 Accessories
Accessories can be equipped with a clamp. This clamp is used to mount the accessories to the
EPoS rail. The mounting and removal of accessories equipped with a clamp is shown in the fol-
lowing with an example of side rail.
5.15.1 Mounting / removing clamps
4
Fig. 31: Mounting / removing clamps
68 / 104
2
3
5
1
Prerequisites:
• Allen wrench is required.
Mounting the clamp
1. Undo the screw
1
Ø The clamp is opened.
2
2. Place the clamp
3
and in doing so hook one side of the
clamp behind the EPoS rail.
2
3. Swivel the clamp fully onto the EPoS rail.
Ø The other side of the clamp is hooked
in behind the EPoS rail.
4. Firmly tighten the screw
wrench.
Ø The clamp
is closed.
2
5. Ensure that the clamp is properly seated.
6. Firmly tighten the setting screw
Allen wrench.
7. Check the secure connection between the
hand control and the EPoS rail.
Removing the clamp
1. Undo the setting screw
wrench.
2. Hold the clamp .
3
3. Undo the screw
1
Ø The clamp is opened.
2
4. Swivel the clamp
3
move from the EPoS rail.
with the Allen wrench.
on the EPoS rail
4
with the Allen
1
with the
5
with the Allen
5
with the Allen wrench.
to the side and re-
