Installation Guide | iC7-Automation Air-cooled Enclosed Drives

Specifications

6

Tightening Torques

6.1
Table 11: Tightening Torques
Frame
FE9, FE10
FE9, FE10, AE10, AE11, IE10, IE11
FE9, FE10, AE10, AE11, IE10, IE11

Cable Sizes

6.2

List of Cable Size Information

6.2.1
Use symmetrical cabling with system modules connected in parallel. Each module must have the same number of cables with an
equal cross-section.
The cable size tables for the enclosed drives can be found with these links.
6.2.2 Mains Cable Size Recommendations, 380–500 V
l
6.2.3 Motor Cable Size Recommendations, 380–500 V
l
6.2.4 Mains Cable Size Recommendations, UL 480 V
l
6.2.5 Motor Cable Size Recommendations, UL 480 V
l
6.2.6 Brake Cable Size Recommendations
l
6.2.7 Brake Cable Size Recommendations, UL
l
34 | Danfoss Drives Oy © 2024.09
Bolt Tightening torque
Nm
M4 1.8
M5 2.7
M6 6
M8 20
M10 40
M12 70
Grounding bolt (M8) 13.5
NOTICE
Specifications
In-lb
16
24
53
180
350
620
120
AN484843731544en-000101 / 172K4825A
