Control and Option Installation

4

Control Compartment Connections

4.1
Table 2: Control Compartment Connections
Terminal
X1
X2
X0
Micro SD
X62
X33
OptionBus
X80
X9
RTC battery
Table 3: STO Terminal Signals (X33, XD2.2)
Terminal on the Function
control board
(1)
41A 24 V
(1)
41B 24 V
42 S.INA+
43 S.INB+
44 S.FB+
(1)
45A GND
(1)
45B GND
46 S.INA-
47 S.INB-
48 S.FB-
1) Terminals 41A, 41B, 45A, and 45B have double pins to make connections easier.
For more information on the STO safety function, see the iC7 Series Functional Safety Operating Guide, Air-cooled and Liquid-cooled System
Modules (AE10, AE11, IE10, and IE11) or the iC7-Automation Functional Safety Operating Guide, Frequency Converters (FE9 and FE10).
18 | Danfoss Drives Oy © 2024.09
Function
Ethernet port
Ethernet port
Ethernet port (used for the PC tool)
microSD card
24 V DC supply
STO terminal
OptionBus (internal connection)
Fiber optic link to power unit or star coupler board
Control panel terminal
RTC battery
Connector type
RJ45
RJ45
RJ45 (Cabled to the door -XD3.1 ethernet terminal)
Micro SD
2 x 3 spring force connector 0.2–1.5 mm
1 x 10 spring force connector 0.2–1.5 mm
Custom
LC-duplex
iX Industrial
BR1632 (battery type)
Terminal block
-XD2.2:41
-XD2.2:41
-XD2.2:42
-XD2.2:43
-XD2.2:44
-XD2.2:45
-XD2.2:45
-XD2.2:46
-XD2.2:47
-XD2.2:48
Control and Option Installation
2
2
Description
+ 24 V DC Output
+ 24 V DC Output
+ Safe Input Channel A
+ Safe Input Channel B
+ STO Feedback
0 V/GND
0 V/GND
- Safe Input Channel A
- Safe Input Channel B
- STO Feedback
AN484843731544en-000101 / 172K4825A
