Installation Guide | iC7-Automation Air-cooled Enclosed Drives
Table 5: I/O and Relay Option Signals
Terminal
X13
X51
X101
X102
X103
Table 6: I/O Terminal Signals (X13)
Terminal Function
11 +24 V
out
12 +24 V
out
13 DI 1
14 DI 2
15 DI 3
16 DI 4
17 DI 5
18 DI 6
19 DGND
20 DGND
21 DO 1
22 DO 2
23 GND
24 GND
20 | Danfoss Drives Oy © 2024.09
Function
I/O terminal
Thermistor input
Relay 1
Relay 2
Relay 3
Terminal block Description
XD2.1:11 Control voltage output.
24 V DC (-15...+20%)
XD2.1:12
Maximum current 200 mA
Short-circuit protected
XD2.1:13 Configurable digital input, galvanically isolated.
24 V DC, 0 < 5 V, 1 > 15 V.
XD2.1:14
Input load 7.5 mA constant current + 10 kΩ resistive load, maximum pulse
XD2.1:15
frequency 100 kHz.
XD2.1:16
XD2.1:17
XD2.1:18
XD2.1:19 Digital input ground, not isolated by default.
When using the internal +24 V
XD2.1:20
tween DGND and GND.
When using the external +24 V DC supply, remove the external jump wire be-
tween DGND and GND.
XD2.1:21 Configurable digital output.
Push-pull 24 V/50 mA
XD2.1:22
Open collector (NPN/PNP) 48 V/50 mA
Short-circuit protected
XD2.1:23 I/O ground.
Ground for digital outputs, +10 V Ref, +24 V
XD2.1:24
outputs.
Connector type
2 x 11 spring force connector 0.2–1.5 mm
1 x 2 spring force connector 0.25–2.5 mm
1 x 3 spring force connector 0.25–2.5 mm
1 x 3 spring force connector 0.25–2.5 mm
1 x 2 spring force connector 0.25–2.5 mm
supply, connect the external jump wire be-
out
(1)
Control and Option Installation
2
2
2
2
2
, analog inputs, and analog
out
AN484843731544en-000101 / 172K4825A
