Danfoss iC7 Installation Manual page 3

Installation Guide | iC7-Automation Air-cooled Enclosed Drives
Contents
Overview
1
1.1 Safety and Installation Awareness
Checking the Delivery and the Contents
1.2
1.3 Lifting the Enclosed Drive
2 Mechanical Installation
2.1 Installation Requirements
2.2 Installing the Enclosed Drive
Installing the Enclosed Drives Back to Back
2.3
2.4 Installing the IP21 Top Cover
2.5 Installing the Back-channel Cooling Option
Electrical Installation
3
3.1 Grounding Principles
Prerequisites for Cable Installation
3.2
3.3 Installing Power Cables
3.3.1 Installing the Power Cables through the Bottom
3.3.2 Installing the Power Cables through the Top (+KCIT or +KDOT)
3.4 Installing the Brake Cables, FE9, FE10
3.5 Power Cabling Floor Components, UL
Checking the Settings for the Auxiliary AC Voltage Transformer (+IHAT)
3.6
3.7 Parameter Settings for IT Mains
4 Control and Option Installation
4.1 Control Compartment Connections
4.2 I/O and Relay Option Connections
Control Cable Routing
4.3
4.4 Installing Boards to the Control Compartment
4.5 Wiring of the I/O and Relay Options
4.6 Installing the Control Cables
4.7 Installing the microSD Card
Danfoss Drives Oy © 2024.09 AN484843731544en-000101 / 172K4825A |
Contents
5
5
5
7
7
7
8
9
11
11
13
13
14
16
16
17
17
18
19
22
26
27
27
30
3
