Table 8: Relay 1 Signals (X101)
Terminal Function
1 COM
2 NO
3 NC
Table 9: Relay 2 Signals (X102)
Terminal Function
4 COM
5 NO
6 NC
Table 10: Relay 3 Signals (X103)
Terminal Function
7 COM
8 NO

Control Cable Routing

4.3
Use the control cable grommets and tubes to route the control cables into the control compartment. There are control cable grommets
at the top and at the bottom of the cabinet.
22 | Danfoss Drives Oy © 2024.09
Terminal block Description
XD2.1:1 Configurable relay output.
Switching capacity:
XD2.1:2
• 24 V DC/8 A
XD2.1:3
• 250 V AC/8 A
• 125 V DC/0.4 A
Minimum switching load: 5 V/10 mA
Terminal block Description
XD2.1:4 Configurable relay output.
Switching capacity:
XD2.1:5
• 24 V DC/8 A
XD2.1:6
• 250 V AC/8 A
• 125 V DC/0.4 A
Minimum switching load: 5 V/10 mA
Terminal block Description
XD2.1:7 Configurable relay output.
Switching capacity:
XD2.1:8
• 24 V DC/8 A
• 250 V AC/8 A
• 125 V DC/0.4 A
Minimum switching load: 5 V/10 mA
