Installation Guide | iC7-Automation Air-cooled Enclosed Drives
See the pin numbering of the I/O and Relay Option in
terminal blocks in
1
2
Figure 24: Example of Installing the Control Cables on the Option Board
1 Control cable
28 | Danfoss Drives Oy © 2024.09
4.1 Control Compartment Connections.
4.2 I/O and Relay Option Connections and the pin numbering of the
2 Cable clamp
Control and Option Installation
AN484843731544en-000101 / 172K4825A
