Installation Guide | iC7-Automation Air-cooled Enclosed Drives
1
2
3
4
L1 L2
5
6
7
8
9
Figure 10: Cabling Principle
1
Control cable grommet
3 Control cables from the top
5
Auxiliary power terminals
7 Auxiliary power cable
9
Mains cable
11 Control board and option boards
13
Strain relief and 360° grounding
15 Motor cable
1
1
Figure 11: Recommended Installation
12 | Danfoss Drives Oy © 2024.09
L3
R- R+
U
V
W
15
10 10
11
12
13
14
16
2
Cable installation tubes, 2 pcs, diameter 32 mm (1.3 in)
4 Strain relief and cable grounding
6
Control cables from the bottom
8 Control cable grommet
10
Grommets
12 Terminal blocks
14
PE busbar
16 Brake cable
2
M
Electrical Installation
AN484843731544en-000101 / 172K4825A
