NOTE
The NEC Versa must be in Suspend mode or powered off
while the monitor is being connected. Otherwise, the system will not
recognize the monitor type.
Open the right-most port cover on the back of the system.
2.
Attach the 15-pin cable connector to the monitor port on the system.
3.
Secure the cable connection with the screws provided.
Connect the monitor power cable and plug it into a properly grounded
4.
wall outlet.
Follow any setup instructions in the monitor's user's guide.
5.
Turn on power to the monitor.
6.
7.
Press the Suspend button to resume Active mode or power on the NEC
Versa 6200MX.
Press
to toggle between the LCD, CRT, simultaneous CRT/LCD
Fn-F3
display, and TV Out.
Connecting a monitor
Using Your NEC Versa 6200MX 4-37
