Parameter Value
Controlled
Out of Service In Service
Out of Service
-32768 to 32767
Deutsch
French
English
Off
Red
-10 to 100
Activated
Deactivated
Yes
Yes
A4
A5
B4
B5
Combined mode
Hold Mode
Pulse Mode
Yes
No
Description
Direction B passage subject to authorisation (see
reader): opens if there is an Open command
Apparatus in service: operates according to the mode
defined in the "Direction A" and "Direction B" parameters
Apparatus out of service: locked in both directions
Code giving Technician or Constructor access to the
level parameters.
Choice of menu language: German
Choice of menu language: French
Choice of menu language: English
Choice of operation pictogram display when at rest: off.
Choice of operation pictogram display when at rest: red
cross
Temperature below which
(connected to output DO9) is switched on.
Activates the electromagnets when temperature drops
below the "Thermostat °C" set-point, in order to heat the
direct surroundings of the electromagnets.
Heating by electromagnets deactivated.
Storage of the Open commands given by the reader in
Direction A.
Storage of the Open commands given by the reader in
Direction B.
Assembly of the electromagnet used for direction A:
mode 4 (=locked when not energised).
Assembly of the electromagnet used for direction A:
mode 5 (= unlocked when not energised).
Assembly of the electromagnet used for direction B:
mode 4 (= locked when not energised).
Assembly of the electromagnet used for direction B:
mode 5 (= unlocked when not energised).
This operating mode combines the following two modes.
If an impulse is given (= signal falls off before detection
of the limit switch or before the no-passage time limit
expires), the apparatus operates in impulse mode;
otherwise it will operate in hold mode.
Passage is managed by the reader: passage is enabled
for as long as the reader input is activated.
Passage is managed by the AS1300: Each reader impulse
enables access for passage. The impulses can be
stored. The obstacle will lock once the cycle has been
completed.
Readers in directions A and B active in high state
(Normally Open contact).
Readers in directions A and B active in the low state
(Normally Closed contact).
the heating element
